City bus 8.6E

The design and small size make the bus in this variant perfect for use in densely built-up areas, housing estates with narrow streets and access lines.

Low-floor along the entire length (without transverse steps). Despite its compact size, it is characterized by a large number of seats, taking up to 65 passengers on board, including up to 23 seated ones. Optionally equipped with batteries with a capacity that allows the mileage of up to 400 km on a single charge.

Description/version Pilea 8.6E city
Dimensions:
Length/Height/Width 8.560 mm / 3.150 mm / 2.460 mm
Loads:
Own load / DMC 10200 kg - 11000 kg / 16700 kg
Passenger compartment:
Seating + standing 23 + 42 = 65
Place for a trolley 1
Engines:
Type and power Permanent motor with synchronous magnets (PMSM) with 245kW engine
Batteries:
Capacity and type NMC from 120 up to 300kWh or LTO with 63kWh
Charging system Plug-in: on-board chargers or external chargers, pantograph
Exterior doors:
Drive Electric or pneumatic
Layout  1-2-0 / 1-2-1
Ramp Hand-folding ramp in second door
Axles and steering system:
Axles Front - independent ZF, back - portal bridge ZF
Assist Hydraulic with electric drive
Suspension Pneumatic suspension with ECAS, 320 mm input height
Brakes:
Type Pneumatic disc
Control EBS, ABS, ASR, ESC, with recuperation system
Heating and air conditioning:
Air conditioning Roof air conditioning with electric drive
Heating Hybrid heating: oil and electric with switching options between modes
Body:
Frame construction Corrosion-resistant steel structure
Side walls Side aluminum panels
Tires:
Wheel size 285/70 R19.5
Lighting:
Front and rear All in LED technology
