EXTRACAPACIOUS

Providing passenger capacity of the MAXI class bus and taking up to 85 people




LOW-FLOOR

along the entire length, no transverse steps








  • A completely Polish project

created in the interest of air cleanliness and noise reduction.

  • Guaranteeing the comfort and safety

of passengers thanks to the low-floor along the entire length.

  • Universal

thanks to the compact dimensions, perfect for servicing cities with narrow streets and compact houses, and thanks to an unprecedented passenger capacity ideal for cities that require a large passenger streams.

  • Stable and agile

thanks to the reduction center of gravity obtaining excellent traction parameters and driving safety.

  • Economical and reliable

thanks to the most modern technology, such as motors with permanent magnets, PILEA 10E reigns in economic operation and reliability.

  • Setting global trends

and awarded at Busworld 2019 and Transexpo 202 fairs.

  • Extracapaciuos

providing passenger capacity of the MAXI class bus and taking up to 85 people.

  • With impressive range

equipped with batteries that allow you to drive over 400 km between charging.

  • Light and compact

thanks to the stainless steel skeleton and the use of polyester laminates ensures safety and reduction of energy consumption by up to 10%.

  • Ultra accessible

with 100% low floor which makes it a great solution for people with movement constraints.



Description/version Pilea 10E city
Dimensions:
Length/Height/Width 10.000 mm / 3.150 mm / 2.460 mm
Loads:
Own load / DMC 10200 kg - 11000 kg / 16700 kg
Passenger compartment:
Seating + standing 27 to 31 + od 40 to 58 = 71 to 85
Place for a trolley 1
Engines:
Type and power Permanent motor with synchronous magnets (PMSM) with 245kW engine
Batteries:
Capacity and type NMC from 120 up to 300kWh or LTO with 63kWh
Charging system Plug-in: on-board chargers or external chargers, pantograph
Exterior doors:
Drive Electric or pneumatic
Layout  1-2-0 / 1-2-1
Ramp Hand-folding ramp in second door
Axles and steering system:
Axles Front - independent ZF, back - portal bridge ZF
Assist Hydraulic with electric drive
Suspension Pneumatic suspension with ECAS, 320 mm input height
Brakes:
Type Pneumatic disc
Control EBS, ABS, ASR, ESC, with recuperation system
Heating and air conditioning:
Air conditioning Roof air conditioning with electric drive
Heating Hybrid heating: oil and electric with switching options between modes
Body:
Frame construction Corrosion-resistant steel structure
Side walls Side aluminum panels
Tires:
Wheel size 285/70 R19.5
Lighting:
Front and rear All in LED technology
